Deye SUN-15/18/20K-SG05LP3-AU-SM2 Low Voltage Three Phase Hybrid Inverter

by DEYE
$5,282.00

Customers please Note:

Shipping is free on most orders within Australia; however, some heavy or bulky items may require specialised freight at additional cost. While we aim to keep shipping free wherever possible, regional and remote areas may attract additional charges depending on location and freight requirements.

For tailored quotes or to confirm shipping costs, please get in touch.
For more details on shipping and delivery, please click here.

Notify me when back in stock

The Deye SUN-SG05LP3-AU-SM2 Series, available in 15kW, 18kW, and 20kW capacities, making this the most powerful range of Low Voltage Three Phase Inverters on the market.

Engineered for three-phase hybrid applications, this inverter series offers seamless integration of solar, grid and battery storage, making it ideal for both on-grid and off-grid energy management.

CEC approval pending for On-Grid and Off Grid applications.

The Deye SGO5 - SM2 series is available in the following power ratings; Click on the drop-down menu to select:

  • SUN-15K-SG05LP3-AU-SM2

  • SUN-18K-SG05LP3-AU-SM2

  • SUN-20K-SG05LP3-AU-SM2

Main Features

Hybrid Operation: Combine solar, grid, and battery power for maximum energy independence.
Low Voltage (48V) Battery Support: Compatible with a wide range of low-voltage lithium or lead-acid battery systems.
Dual MPPT Inputs: Achieve greater design flexibility and improved yield with two independent MPPTs.
Built-In Battery Management: Smart control for charging and discharging to maximise battery life.
Three-Phase Output: Perfect for larger residential, commercial, or agricultural systems.
Blackout Protection: UPS-level switching (<10ms) ensures uninterrupted power during grid outages.
High Efficiency: Up to 97.6% conversion efficiency ensures superior performance and energy savings.
Scalable Design: Supports parallel operation for larger systems (up to 10 units).
Remote Monitoring: Integrated WiFi or optional LAN for easy system control and analytics

Quick Specs

Feature Details
Output Power 15kW / 18kW / 20kW
Phase Type Three Phase
MPPTs 2 Independent MPPT Trackers
Battery Voltage 48V (Low Voltage)
Communication CAN, RS485, WiFi
Grid Support V/F control, power export limitation, zero-export ready
Certification AS4777, IEC62109, CE

Why Choose The DEYE SG05LP3-AU-SM2 Series?

  • Australian Standard Compliant: Fully certified and approved for Off-Grid use in Australia (CEC Approval Pending for On-Grid use)
  • All-in-One Inverter System: Reduces installation time and simplifies system design.
  • Reliable & Flexible: Whether you’re retrofitting an existing system or starting from scratch, Deye’s hybrid inverter adapts to your energy goals.

Use Cases:

  • Homes and businesses with high power demand
  • Sites requiring blackout protection or energy storage
  • Hybrid solar installations with three-phase loads

DEYE Three-Phase Hybrid Inveter Comparison Table
Model: SUN-15K / 18K / 20K-SG05LP3-AU-SM2

Feature SUN-15K SUN-18K SUN-20K
Rated AC Output Power 15,000 W 18,000 W 20,000 W
Max AC Output Power 15,000 VA 18,000 VA 20,000 VA
Max PV Input Power 19,500 W 23,400 W 26,000 W
MPPTs / Strings per MPPT 2 MPPT / 2 strings each 2 MPPT / 2 strings each 2 MPPT / 2 strings each
Max Input Voltage (PV) 1000 V 1000 V 1000 V
Startup Voltage 150 V 150 V 150 V
Battery Type 48V Li-ion / Lead-acid (LV) 48V Li-ion / Lead-acid (LV) 48V Li-ion / Lead-acid (LV)
Max Charge/Discharge Power 15,000 W 18,000 W 20,000 W
Efficiency (Max / Euro) 97.6% / 97.0% 97.6% / 97.0% 97.6% / 97.0%
Parallel Support Up to 10 units Up to 10 units Up to 10 units
Backup (EPS) Switching Time <10 ms <10 ms <10 ms
Dimensions (W × H × D) 515 × 700 × 240 mm 515 × 700 × 240 mm 515 × 700 × 240 mm
Weight Approx. 37 kg Approx. 38 kg Approx. 39 kg
IP Rating IP65 (indoor/outdoor) IP65 (indoor/outdoor) IP65 (indoor/outdoor)
Monitoring WiFi / RS485 / CAN / Optional LAN WiFi / RS485 / CAN / Optional LAN WiFi / RS485 / CAN / Optional LAN
Compliance AS4777, IEC62109, CE AS4777, IEC62109, CE AS4777, IEC62109, CE
